K 470 - IP 67

SKU: 380378

Details

ZARGES K 470 - IP 67: optimised protection against water and dust.

TÜV-certified box with extra-large pressure compensation valve – optimal protection against dust and water.
New patented combination of hinge and fastener.
Customised versions available on request.
High-quality special container made from aluminium.
Extra-large pressure compensation valve.
Leak-tightness verified with TÜV SÜD certificate.
Protection class IP 67 in accordance with DIN EN 60529 : 2014
Extra thick 1.5-mm sheet metal for all K 470 containers from basic dimensions of 750 x 550 mm.
Profile-section joints fully welded.
Special sizes on request.
Cast-aluminium stacking corners.
Ergonomic carrying handles.
Ergonomic & durable C. fasteners for at least 20,000 operating cycles.

Clearance measurement approx. 30mm (1.2") less than internal dimension (length and width). Special sizes on request.
Special inside inserts available on request.

More Information
Order number	380378
Internal dimensions L x W x H	750 mm × 550 mm × 580 mm
Outside dimensions L x W x H	800 mm × 600 mm × 610 mm
Corner beading	✔
Warranty	10 years
Volume	239 l
Material	Aluminium
Protection class	IP67:
Colour of the stacking corners	Natural aluminium
Number of handles	2
Seal	EPDM cellular rubber
Fasteners	Comfort fasteners
Material of the stacking corners	Aluminium
Weight	12 kg
Peripheral beads and corner beads	✔
Stacking corners	✔

Order number	Internal dimensions L x W x H	Outside dimensions max. L x W x H	Volume	Weight
380366	550 mm × 350 mm × 380 mm	600 mm × 400 mm × 410 mm	73 l	5.3 kg
379083	750 mm × 550 mm × 380 mm	800 mm × 600 mm × 410 mm	157 l	10 kg
380378	750 mm × 550 mm × 580 mm	800 mm × 600 mm × 610 mm	239 l	12 kg
379725	900 mm × 640 mm × 450 mm	950 mm × 690 mm × 480 mm	259 l	13.4 kg
